Auxiliary Equipment for Flask Molding Line, Casting Machine

Auxiliary Equipment for Flask Molding Line, Casting Machine

Auxiliary equipment for flask molding line We supply auxiliary equipment for molding machine,which purchased from Europe
Basic Info
Type Sand Casting
Specification Non-standard
Trademark Suzhu
Origin Suzhou, China
HS Code 8474809090
Production Capacity 15 Sets/Year
Product Description
Auxiliary equipment for flask molding line
We supply auxiliary equipment for molding machine,which purchased from Europeean.Not only ensure the good performance of the molding line,but also got more ore cost-effective products We can provide design,manufacturing,installtion and commissioning,covers the following device:
1.flask separating device
2.flask inside and outside cleaning device
3.pattern bolster
4.pattern changing device
5.turnover device
6.locating device
7.core setting device
8.roller conveyor
9.downgate drilling device
10.vent hole drilling device
11.flask closing device
12.punch-out device
13.pallet car surface cleaning
14.hydraulic system
15.electric system
16.spare parts
Static Pressure Horizontal Automatic Molding Line

Product Detail:

Productivity of moulding linesup to 210 mould per hour achieved Plants with higher productivity may be designed on request.Size of moulds up to 2500 mm lengthPlants with larger flask may be designed on request.

Product Orientation

1. High ability for compaction sand, rigid and dense mould, suitable to manufacture of complex castings.
2. Dimensional stability and better surface roughness ,high efficiency of moulding
3. Mould plate with high rate of utilization. Good working condition and labour saving



A. Process of molding machine

1. Empty Flask is indexed into the molding machine molding station
2. Pattern bolsters rotate or shuttle
3. The lifting cylinder rises, and the formwork, sand box and pre-sand frame rise
4. Quantitative sand adding
5. Move the sand bucket out while moving the multi-contacts in and clean the upper surface of the pre-sand frame
6. The lifting cylinder goes up again to top tight
7. Air pre-compacting and compaction
8. The lifting cylinder falls down while drafting



Static Pressure has following advantages.
High ability for compaction sand, rigid and dense mould, suitable to manufacture of complex castings.
Dimensional stability and better surface roughness.
High efficiency of moulding.
Mould plate with high rate of utilization.
Good working condition and labour saving.

-PLC from SimensS7, with touch screen and network Ethernet etc.
-Servo system from SEW or Siemens and and Variable-Frequency Drive from Rexroth.
-Hydraulic valve of moulding machine from Rexroth, Hydraulic Cylinder from China famous brand.
-Low-voltage electrical components from Schneide.
-Hydraulic Seals from international brand.
-Bearing from China famous brand (HRB/LYC/ZWZ).
